Machine Roll Stretch Wrap Film

Machine Roll Stretch Wrap Film by Innovative WrapTech Pvt. Ltd. for secure and efficient industrial packaging.

Innovative Wraptech Pvt. Ltd. manufactures premium Machine Roll Stretch Wrap Film engineered for high-speed automated pallet wrapping. Delivering exceptional load stability and high puncture resistance, our stretch film ensures maximum protection and security for heavy cargo during transit and storage.

Designed for superior stretchability and yield, our film optimizes material usage to significantly reduce waste and operational packaging costs. Partner with Innovative Wraptech Pvt. Ltd. to streamline your warehouse workflow with dependable, high-efficiency wrapping solutions.

Enquiry

Enquiry Form

    captcha

    Video
    Youtube Video
    Features :

    • High Pre-Stretch: Maximizes yield to lower material costs.

    • Tear-Resistant: Protects sharp edges and heavy pallet loads.

    • Strong Load Hold: Ensures tight containment during transit.

    • High Clarity: Enables easy barcode scanning and inspection.

    • Machine-Ready: Designed for seamless, high-speed automated application.

    Specification
    WORKING PRODUCT DIAMETER
    		Width : 400 MM To 1500 MM
    Diameter : 1000 To 1500 MM
    Kg : 300 To 1200
    DIAMETER OF ROLL (STRETCH FILM)
    		CORE ID : 75 MM
    OD : UP TO 200 MM
    WIDTH : 300 To 500 MM
    PACKING EFFICIENCY
    		10-20 Rolls/Hour (Depend on Product )
    ROLLER SPECIFICATION
    		Rollers : 2 Nos. (M.S)
    Roller : M.S Roller With Rubber Belt
    Dia. Of Roller : 170mm
    Roller Center Distance : 200 mm
    Motors
    		Roller Motor : 3 HP
    Power Pre-Stretch Motor : 0.25 HP (2 Nos)
    Sliding System Motor : 0.5 HP
    MOTOR WORM GEAR BOX
    		Roller Motor : 3 HP Gear Box
    Power Pre-Stretch Motor: 0.25 HP Gear Box (2 Nos)
    Sliding System Motor : 0.5 HP Gear Box
    MOTOR DRIVE (V.F.D)
    		Roller Conveyor : 3 Hp
    Power Pre-Stretch Motor: 0.25 HP (2 Nos)
    Sliding System Motor : 0.5 HP
    SLIDING SYSTEM
    		Chain Base Sliding System With Motor And Linear Shaft
    PRE-STRETCH SYSTEM
    		Rubber Mounted Roller Base Automatic Cancer Base
    Power Pre-Stretch System
    Product Extra Detail

    What the Product Is and How It Works

    The Machine Roll Stretch Film is a high-performance industrial solution designed to wrap rolls of paper, textiles, and other cylindrical products using stretch film. It protects rolls from dust, moisture, handling damage, and edge tears during storage and transportation.

    Step-by-Step Technical Operation:

    1. Roll Loading: The operator places the roll on the rotating platform or conveyor system.

    2. Film Feeding: The stretch film is loaded onto the film carriage and threaded automatically.

    3. Tension Control: The machine adjusts film tension to prevent tearing while ensuring tight wrapping.

    4. Rotational Wrapping: The roll rotates while the film carriage moves axially (radial or orbital), covering the entire surface.

    5. Layer Control: The system controls the number of film layers, optimizing material usage.

    6. Film Cutting & Sealing: Once wrapping is complete, the film is automatically cut and sealed for a secure finish.

    7. Roll Discharge: Wrapped rolls are unloaded manually or via a conveyor system for storage or shipping.

    This process ensures uniform, high-speed wrapping and minimizes human error, delivering professional-grade packaging every time.

    Why This Machine Is Important in Modern Industrial Operations

    Modern industrial operations demand speed, efficiency, and product protection. Machine Roll Stretch Film:

    • Reduces damage to valuable rolls during handling and transport

    • Saves stretch film through optimized tension and layering

    • Improves packaging speed, supporting high-volume production

    • Reduces labor costs, allowing operators to manage multiple machines

    • Ensures consistent quality, essential for logistics and customer satisfaction

    Industries such as paper mills, textile manufacturing, packaging plants, and logistics companies rely on this machine for reliable and cost-efficient operations.

    How to Choose the Right Machine

    1. Capacity Requirements

    • Maximum roll diameter, width, and weight

    • Daily throughput and production targets

    • Select semi-automatic for moderate volume or fully automatic for continuous production

    2. Material Compatibility

    • Kraft paper rolls, tissue rolls, cardboard, and other cylindrical products

    • Ensure the machine supports your product dimensions and weight ranges

    3. Level of Automation

    • Manual loading for low-volume operations

    • Semi-automatic for balanced efficiency and cost

    • Fully automatic with conveyor integration for high-volume continuous production

    4. Budget Considerations

    • Factor in film savings, labor reduction, and reduced product damage

    • Professional-grade machines offer long-term ROI, durability, and low maintenance

    Energy and Power Requirements

    • Operates on standard industrial voltage (220–440V AC, 50/60Hz)

    • Typical power consumption: 1–3 kW, depending on roll size and automation

    • Low-energy design reduces operational costs while maintaining high efficiency

    Frequently Asked Questions

    1. What industries use this machine?

    Paper mills, textile units, packaging plants, and logistics companies.

    2. Can it handle large, heavy rolls?

    Yes. The machine is engineered for heavy-duty industrial rolls, ensuring secure and uniform wrapping.

    3. Does it save material?

    Yes. Optimized tension and layer control reduce stretch film usage, lowering costs.

    4. Is it easy to operate?

    Yes. Intuitive HMI controls and automated processes require minimal operator training.

    5. Can it integrate with conveyors?

    Yes. Fully automatic versions integrate with infeed and outfeed conveyor systems.
