Rotary Arm Stretch Wrap Machine

Rotary Arm Stretch Wrap Machine by Innovative WrapTech Pvt. Ltd. for high-speed and secure pallet wrapping.

Innovative Wraptech Pvt. Ltd. offers high-speed packaging efficiency with its Rotary Arm Stretch Wrap Machine. By keeping pallet loads stationary while an overhead arm rotates, it provides superior film application and exceptional load stability for unstable, lightweight, or heavy cargo.

Engineered for industrial reliability, this machine reduces film consumption and seamlessly integrates into existing production lines. Innovative Wraptech Pvt. Ltd. ensures dependable end-of-line protection, delivering maximum throughput with minimal maintenance.

Enquiry

Enquiry Form

    captcha

    Video
    Youtube Video
    Features :

    • Stationary Load Design: Wraps pallets in place, ideal for unstable, lightweight, or ultra-heavy loads.

    • High-Speed Operation: Overhead rotating arm accelerates wrapping cycles for maximum throughput.

    • Pre-Stretch Film Savings: Motorized pre-stretch system reduces stretch film consumption by up to 300%.

    • Fully Automated Integration: Integrates into existing inline conveyor systems for hands-free packaging.

    • Customizable Wrap Profiles: Adjustable rotation speed, film tension, and top/bottom wrap count controls.

    Specification
    Pallet Size MMLength : 800 Min To 1100
    Width : 800 Min To 1200
    Height : 800 Min To 1500
    Weight Capacity200 Kg To 1500 Kg
    Power415 V. A.C
    3 Phase + Neutral + Earthing (415 V AC 50 Hz)
    Turntable Dia
    		1650 MM
    MotorARM Motor : 1 Hp
    Pre-Stretch Motor : 0.25 Hp
    Up-Down System Motor : 0.5 Hp
    Conveyor Motor : 1 Hp
    Turntable Speed
    		Up to 15 rpm
    Turntable Drive
    		Arm Drive : 1 HP
    Pre-Stretch Drive : 0.25 Hp
    Up-Down System Drive : 0.5 Hp
    Conveyor Drive : 1 Hp
    Stretch Film Roll DiameterUp to 20 ” Max
    ID : Up To 3”
    OD : Up To 10”
    Control System
    		Combo Plc
    8 Input output plc.
    Relay
    Switches Technique Make
    Eye Sensor for Auto Height
    Product Extra Detail

    A Rotary Arm Stretch Wrapper is an advanced pallet wrapping machine that secures palletized loads by rotating a mechanical arm around a stationary pallet. The machine applies stretch film with controlled tension, ensuring uniform load stabilization without moving the pallet itself.

    Innovative WrapTech Pvt. Ltd. designs rotary arm stretch wrappers for heavy, fragile, tall, or unstable loads that require maximum safety and wrapping precision.

    Why This Machine Is Important in Modern Industrial Operations

    Modern industries demand speed, consistency, and safety. Rotary arm stretch wrappers meet these demands where conventional turntable systems fall short.

    Key Operational Advantages:

    • Keeps heavy and unstable pallets stationary

    • Prevents load collapse during wrapping

    • Supports high-speed continuous packaging

    • Reduces labor dependency and manual effort

    • Optimizes stretch film usage through pre-stretch technology

    • Integrates seamlessly with conveyor systems

    Manufacturers rely on rotary arm stretch wrappers to increase throughput while maintaining packaging quality and workplace safety.

    How to Choose the Right Rotary Arm Stretch Wrapper

    1. Capacity Requirements

    Evaluate pallets per hour and peak production demand. High-volume plants benefit from fully automatic systems with conveyors.

    2. Material Characteristics

    Choose rotary arm systems for fragile, tall, uneven, or heavy pallet loads.

    3. Level of Automation

    • Semi-automatic: Medium production lines

    • Fully automatic: High-speed, end-of-line packaging

    4. Budget Considerations

    Balance initial investment with long-term savings in labor, film consumption, and reduced product damage.

    Innovative WrapTech provides expert guidance to match machine specifications with operational needs.

    Reasons Manufacturers Prefer Professional-Grade Machines

    Manufacturers choose Innovative WrapTech Pvt. Ltd. for:

    • Robust industrial-grade construction

    • Consistent wrapping performance

    • Energy-efficient operation

    • Custom automation capabilities

    • Reliable after-sales service and support

    Professional-grade machines deliver long service life and high return on investment.

    Frequently Asked Questions

    Q1. Why choose a rotary arm stretch wrapper over a turntable machine?

    A rotary arm system keeps the pallet stationary, making it ideal for heavy or unstable loads.

    Q2. Can the machine handle different pallet sizes?

    Yes. Programmable controls allow flexible wrapping for varied pallet dimensions.

    Q3. How much stretch film can be saved?

    Pre-stretch systems reduce film consumption by up to 40%.

    Q4. Is the machine suitable for automated production lines?

    Yes. Fully automatic models integrate easily with conveyors and smart factory systems.

    Q5. What is the expected service life of the machine?

    With proper maintenance, the machine delivers reliable performance for 10–15 years.

    Conclusion

    A Rotary Arm Stretch Wrapper from Innovative WrapTech Pvt. Ltd. is a strategic investment for manufacturers seeking secure, efficient, and safe pallet packaging. Its ability to handle complex loads while supporting automation makes it essential for modern industrial operations.
